Place of Origin: | Hangzhou, Zhejiang, China |
---|---|
Brand Name: | Peritek |
Certification: | ISO9001:2008 |
Model Number: | ZLB-Z-3000 |
Minimum Order Quantity: | 1 SET |
Packaging Details: | Wooden cases,a normal export package. Details: wrapping film,fixed,waterproof plastic bag and wooden cases. |
Delivery Time: | Within 30 days after receipt of down payment. |
Payment Terms: | L/C,T/T |
Supply Ability: | 1000 Set/Sets per Month |
Highlight: | High Moisture Removal Industrial Dehumidifiers,High Moisture Removal Chemical Dehumidifier,Larger Airflow Chemical Dehumidifier |
---|
Larger Airflow Chemical Dehumidifier Machine High Moisture Removal
Quick Detail:
Chemical Desiccant Adsorptiono Rotor Dehumidifier , Chemical Dehumidifier
Mainly used in laminated safety glass and glass manufacturing. For example: film room together, laminating room.
Plastic film laminated safety glass in transparent thin have a strong moisture absorption. Suck the moisture film, will emerge in the manufacturing process to produce steam bubbles. Confined to control the relative humidity in this very important process. Standard design conditions for this application are: at 25% relative humidity and comfortable temperatures.
Description:
Except the desiccant wheel, ZLB series low humidity dehumidifier also equipped with pre and after cooling coils. It process with and dehumidify normal temperature air, it is specialized dehumidifier for normal temperature and low humidity process environment. As follow are their major characteristics:
Character:
Model Example:
ZLB-D-1000
ZLB: low humidity dehumidifier units basic code
D: Rotary regeneration type. D for Electricity, Z for Steam.
1000: Process airflow m3/h
Main Parameters of ZLB Series Dehumidifier:
Main Parameters / Model |
ZLK-120 |
ZLK-200 |
ZLK-1000 |
ZLK-6000 |
|
Process Air |
Airflow m³/h |
120 |
200 |
1000 |
6000 |
Fan Power kW |
0.085 |
0.08 |
1.1 |
5.5 |
|
Reactivation Air |
Airflow m³/h |
40 |
68 |
330 |
2000 |
Fan Power kW |
0.085 |
0.08 |
0.37 |
1.5 |
|
Reactivation Mode |
Electrical Heating Power kW |
1.5 |
1.5 |
8.4 |
60 |
Steam Consumption kg/h |
/ |
/ |
14 |
100 |
|
Dehumidify Capacity |
20°C,70%,kg/h |
0.6 |
1.5 |
7.2 |
45.9 |
Drive Motor Power kW |
0.015 |
0.015 |
0.04 |
0.1 |
|
Installed Power |
Electrical Heating kW |
1.685 |
1.675 |
9.91 |
61.6 |
Steam Heating kW |
/ |
/ |
1.51 |
1.6 |
|
Overall Dimensions |
Length mm |
360 |
450 |
650 |
1800 |
Width mm |
340 |
450 |
650 |
1300 |
|
Height mm |
800 |
850 |
1750 |
2080 |
|
Weight kg |
35 |
50 |
120 |
700 |
Note:1. Air flow above 4000 without process fan, users can select.
2. If regeneration heating type select steam, P=0.4MPa.
3. Larger airflow dehumidifiers can be customized.
Competitive Advantage:
Typical Application Fields:
Output temperature is below 18 degree, dew point td is below -8 degree. Be used for mixing workshop, coating workshop, production workshop, assembling workshop, etc, enable environmental index of these workshops to achieve 20-24degree, RH below 20%.
1. Warehouse, Library and Archives:
2. Pharmaceutical Industry:
3. Electronics Industry, Lithium Battery
4. Chemical Fiber Industry:
5. Food Processing Industry:
6. Space and Aviation:
7. Glass Lamination
8. Ship Coating
9. Bridge Anticorrosion
10. Rubber Tire
11. Nuclear power plants
12. Printing
Work Principle:
The core component of rotary dehumidifier is the 8-16 hour spin in turn densely cellular Conde desiccant wheel.
The desiccant wheel on both sides by high-performance silicon fluorine rubber seals along the entire surface of
the radial will be divided into 270 ° of the treatment area and 90 ° of the regeneration zone, when the moist air
comes into the processing area, the air moisture in the desiccant wheel was adsorbed into dry air, dry air meet
the need of dry place or gas production process
